01 PROTECTING CRITICAL INFRASTRUCTURE FROM LIGHTNING STRIKES
The Angle Steel Lightning Tower is a four-leg lattice structure. It is installed next to substations, power plants, and industrial facilities. The tower is taller than the structures it protects. At the top, it has a lightning rod. When lightning strikes, the tower carries the electrical current safely to the ground. This protects expensive equipment and keeps workers safe. This is not a transmission tower. It is a protective device.
02 TECHNICAL SPECIFICATIONS
|
Parameter |
Specification |
|
Structure Type |
Four-leg angle steel lattice |
|
Tower Height |
50 to 160 feet |
|
Leg Material |
Equal angle steel |
|
Cross-Section |
Square |
|
Lightning Rod |
Included (single or multi-point) |
|
Down Conductor |
Copper or aluminum cable |
|
Grounding |
Connection to ground electrode |
|
Corrosion Protection |
Hot-dip galvanizing |
|
Protection Radius |
Based on tower height |
|
Applications |
Substations, plants, tank farms |
03 PRODUCTION EQUIPMENT
Using Steel Lattice Construction for Stability
The Angle Steel Lightning Tower uses four angle steel legs. Cross members and diagonals provide bracing. The structure is stable and strong. It can stand on its own without guy wires. The lattice design is open. This allows wind to pass through, reducing wind pressure. The tower is reliable in all weather conditions. We design it to handle storms and heavy rain.
04 OVERALL VIEW
Precision Cutting for a Perfect Fit
Our CNC machines cut and drill the angle steel for the Angle Steel Lightning Tower. The holes are exact. The members are cut to the right length. We mark each piece with a code. The code matches the assembly drawing. This makes on-site assembly quick and easy. Your crew can follow the drawing and put the tower together with simple tools.
05 ON-SITE CONSTRUCTION DRAWINGS
Galvanized to Withstand Weather
All steel parts of the Angle Steel Lightning Tower are hot-dip galvanized. The zinc coating protects against rain, snow, and humidity. The tower is in service for many years. The galvanized surface requires very little maintenance. We also provide the lightning rod and the down conductor system. The down conductor is connected to the ground electrode. This creates a complete path for the lightning current.
06 CERTIFICATIONS
Comprehensive Lightning Protection Solution
We supply more than just the Angle Steel Lightning Tower. We supply the lightning rod, down conductor, and grounding connectors. Our team calculates the protection zone for your site. We confirm the tower height provides the necessary coverage. We can also recommend the grounding design. This gives you a complete solution for lightning protection.
